Chevy Cylinder Head 5.3L V8 706/862 Aluminum, Year:99-06
Chevy Cylinder Head 5.3L V8 706/862 Aluminum, Year:99-06
-5%
Chevy Cylinder Head 5.3L V8 706/862 Aluminum, Year:99-06
Chevy Cylinder Head 5.3L V8 706/862 Aluminum, Year:99-06
Chevrolet

Chevy Cylinder Head 5.3L V8 706/862 Aluminum, Year:99-06

SKU: ALL-20314

$325.00 $345.00
save $20
Ships from East Point, GA
  • 1 Year Warranty: First 90 days include labor
  • Fast Shipping: Ships from East Point, GA
  • Precision Machined: CBN and PCD resurfaced, vacuum & pressure tested
  • Quality Assured: Every casting inspected & stamped
I'm unsure if it will fit my vehicle

Warranty Information (12 Months from Purchase)

First 3 months:
Covers cylinder head repair/replacement, gasket set, fluids/filters, and labor (up to 10 hours at $25/hr).
Remaining 9 months:
Covers cylinder head repair/replacement, gasket set, and fluids/filters (labor not included).
Warranty becomes void if:
There is improper installation, overheating (heat tab damaged/missing), insufficient oiling, or faulty cooling system operation.
Important conditions:
Cylinder head must be returned uncleaned and fully assembled. Any disassembly voids warranty. Proof of purchase required. No warranty on threaded bolt holes after installation.
Read the full warranty (PDF)
Chevy Cylinder Head 5.3L V8 706/862 Aluminum, Year:99-06
$325.00 $345.00
Chevy Cylinder Head 5.3L V8 706/862 Aluminum, Year:99-06
$325.00 $345.00
$325.00
Edit

Part#: ALL-20314

Manufacturer: Chevrolet

Year Range: 99-06

Engine Size: 5.3L - 327ci - V8

Description: 99-06 Chevy 5.3L V8 706/862 Aluminum Cylinder Head

At Allied Motor Parts, we understand the importance of having quality components for your engine. Our Chevy Cylinder Head 5.3L V8 706/862 Aluminum, Year: 99-06 is engineered to deliver top-notch performance for your 5.3L V8 engine, providing you with the reliability and power you need to keep your vehicle running smoothly.

Whether you're working on a 5.3 Vortec engine or upgrading your existing setup, our 706 heads for sale are a perfect fit. 706 LS heads are designed with precision and high-quality aluminum, ensuring durability and maximum efficiency for long-lasting performance. The 5.3 Vortec head delivers increased airflow and superior combustion, helping you achieve better throttle response and overall engine power.

If you're looking for a reliable solution for your engine rebuild, this 5.3 Vortec heads set is just what you need. Our 706 head offers a perfect fit for any project requiring a 5.3 cylinder order and comes with all the components necessary for a seamless installation. Plus, if you're in the market for 862 heads for sale, we've got you covered with excellent deals on premium Chevy cylinder heads.

Our Chevy 5.3 heads are designed to handle high-performance applications, providing the perfect balance of power and efficiency. This cylinder head is engineered to support 706 heads for 5.3, helping your engine achieve optimal performance with enhanced fuel efficiency.

Looking for the 706 5.3 heads? Our cylinder heads for 5.3 Vortec cylinder numbers are a great choice for those looking to upgrade their engine’s performance. Don't settle for anything less than the best—choose 5.3 LS 706 heads for superior power and performance.

Upgrade your engine with the best. Shop our Chevy Cylinder Head 5.3L V8 706/862 Aluminum now!

If you have a question about Chevy Cylinder Head 5.3L V8 706/862 Aluminum, Year:99-06? Contact our expert support team if you need help or have questions by using our contact form, calling 866-766-9955, or emailing sales@alliedmotorparts.com. We're here to assist you throughout your journey. To get insights on cylinder heads, visit our blog.

Learn more about Chevrolet Cylinder Heads.

This Cylinder Head has a core charge of $50.00 included in the cost. This charge is FULLY REFUNDED upon return. We will include a prepaid label for the return freight.

The cylinder head included in this listing will fit the vehicles listed below. It is also important to review/confirm the fitment notes above to ensure the vehicle specifics of the head are correct for your application. If you have any questions that this may not be the correct head for your vehicle or need help locating the correct head, don't hesitate to get in touch with us via phone or email before making a purchase.

MAKE MODEL YEAR ENGINE
Buick Rainier 2004-2005 5.3L 323Cu. In. V8 GAS OHV
Chevrolet Avalanche 1500 2002-2005 5.3L 323Cu. In. V8 GAS OHV
Chevrolet Express 1500 2003-2005 5.3L 323Cu. In. V8 GAS OHV
Chevrolet Express 2500 2003-2005 5.3L 323Cu. In. V8 GAS OHV
Chevrolet Express 3500 2003-2005 5.3L 323Cu. In. V8 GAS OHV
Chevrolet Silverado 1500 1999-2005 5.3L 323Cu. In. V8 GAS OHV
Chevrolet Silverado 2500 1999-2005 5.3L 323Cu. In. V8 GAS OHV
Chevrolet Silverado 3500 2004-2005 5.3L 323Cu. In. V8 GAS OHV
Chevrolet Sonora 2003-2006 5.3L 323Cu. In. V8 GAS OHV
Chevrolet Suburban 1500 2000-2005 5.3L 323Cu. In. V8 GAS OHV
Chevrolet Tahoe 2000-2005 5.3L 323Cu. In. V8 GAS OHV
Chevrolet Trailblazer EXT 2005 5.3L 323Cu. In. V8 GAS OHV
GMC Envoy 2005 5.3L 323Cu. In. V8 GAS OHV
GMC Envoy XL 2003-2005 5.3L 323Cu. In. V8 GAS OHV
GMC Envoy XUV 2004-2005 5.3L 323Cu. In. V8 GAS OHV
GMC Savana 1500 2003-2005 5.3L 323Cu. In. V8 GAS OHV
GMC Savana 2500 2003-2005 5.3L 323Cu. In. V8 GAS OHV
GMC Sierra 1500 1999-2005 5.3L 323Cu. In. V8 GAS OHV
GMC Sierra 2500 1999-2000 5.3L 323Cu. In. V8 GAS OHV
GMC Yukon 2000-2005 5.3L 323Cu. In. V8 GAS OHV
GMC Yukon XL 1500 2000-2005 5.3L 323Cu. In. V8 GAS OHV
Isuzu Ascender 2003-2004 5.3L 323Cu. In. V8 GAS OHV

Not sure this is your casting? Call 866-766-9955 with your casting number and your vehicle's year, make and engine, and we'll confirm it before you buy.

Cylinder Head Rebuilding Process

1. Initial Inspection: As a unit comes to our shop, we give it an initial inspection to determine whether there is any reason the head should not proceed to rebuilding. This quickly catches problems such as cracks, casting damage and other conditions that would halt the process for that casting.

2. Teardown: The cylinder head is fully disassembled, which reveals other areas of potential damage to the casting. The parts and the head are separated and go through different cleaning processes.

3. Cleaning: Cast iron heads are cleaned in a thermal cleaning system — baked at 600° to reduce grease and oil to ash, then put through a steel-shot machine for a brilliant finish. Aluminum heads are baked at a lower temperature or put through a high-pressure wash, then glass-beaded.

4. Head Inspection: After cleaning, heads are pressure tested or Magnafluxed to find any cracks. All bolt holes, valve guides, valve seats and other areas are inspected for broken bolts, broken taps, cracked guides and other impairments. Straightness and cam bore wear are also checked.

5. Machining: All heads have guides installed to meet OE conditions and are resurfaced to far exceed factory specifications for surface finish. A three-angle valve job achieves valve seat runout under .001". Valves are ground for a perfect seal between valve and seat.

6. Assembly: New OE-style valve guide seals are installed. Springs are tested for proper seat pressure. Valve seat sealing is vacuum-checked for an airtight fit. Lifters are bled and rebuilt for zero lash after startup. Cams are polished and clearances are checked twice to meet OE oil clearances.

7. Final Inspection: Every head is visually inspected — surface finish, lash, bolt holes and all other areas — to ensure a quality cylinder head.

Questions about our cylinder head services? Call 1-866-766-9955.

Warranty — 12 months from purchase

Match the head before installation. We will not warranty an incorrectly installed head. Call us immediately with any questions or concerns about your purchase.

First 3 months:

  1. Repair or replacement of the cylinder head.
  2. Gasket set supplied for reinstallation.
  3. Labor calculated from book time at $25.00 per hour, up to a maximum of 10 hours.
  4. Replacement of fluids and filters.

Remaining 9 months:

  1. Repair or replacement of the cylinder head.
  2. Gasket set supplied for reinstallation.
  3. Replacement of fluids and filters.
  4. No labor is covered.

Warranty is void if:

  1. The head was improperly installed.
  2. The head was overheated (heat tab melted or missing).
  3. The head received insufficient oiling.
  4. The cooling system operated improperly.

Warranty returns must be sent to Allied Motor Parts uncleaned and fully assembled — any disassembly voids the warranty — and must be accompanied by proof of purchase. There is no warranty on threaded bolt holes after installation.

This warranty is in lieu of any other warranty, expressed or implied, including any implied warranty of merchantability or fitness for a particular purpose.

Download the full process & warranty (PDF)

Here’s why our cylinder heads stand out:

Thorough Inspection: Every head undergoes a complete teardown, cleaning, and detailed inspection for cracks and imperfections.

Advanced Cleaning: Thermal cleaning for cast iron and high-pressure washing for aluminum ensures a brilliant finish.

Precision Machining: CBN resurfacing, triple-angle valve cuts, and guide installations exceed OEM specifications.

Rigorous Testing: Vacuum tests, tension checks, and pressure tests guarantee performance and durability.

High-Quality Components: New seals, plugs, and rebuilt lifters ensure optimal functionality.

Final Assurance: Each head is inspected, stamped, and stored in a climate-controlled environment.

Wide Availability: Over 2,000 cylinder heads for all makes and models, ready for repair or exchange.
